12 Dc Motor 9000 Rpm Brush Micro Motor 6-24v Is Available

12V DC Motor 9000 RPM Brush Micro Motor 6-24V Is Available

Promotion

Product Description

12 Dc Motor 9000 Rpm Brush Micro Motor Specification

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
		Operating Range	Nominal	Speed	Current	Speed	Current	Torque	Power	Current	Torque
		Operating Range	Nominal	RPM	A	RPM	A	mN.m / gf.cm	W	A	mN.m / gf.cm
RS-380SH	4052	3.0~6.0	4.8VDC	7800	0.32	6701	1.95	9.9/101	6.98	11.9	70.6/720
RS-380SH	3557	6.0~12.0	12VDC	21200	0.44	18367	2.85	11.26/114.9	21.68	18.5	84.3/860
RS-385SH	17110	6.0~24.0	24VDC	11000	0.15	9034	0.69	10.7/109	10.12	3.16	59.8/610
RS-385SH	2267	6.0~12.0	12VDC	10000	0.17	8340	0.85	7.5/76.5	6.53	4.29	45/459

Application

Our Company

Our factory has been established in 2005. It's a high-tech enterprise integrating the research, development, production and sales of various kinds of micro DC motor, geared motor, planetary geared motor, shade pole geared motor and special gearbox motor. Products are widely used in automobiles, communications equipment, smart home, medical equipment, intelligent security, household appliances, western kitchen equipment, machinery and electronics and other high-end transmission structures. Products are exported to more than 50 countries and regions at home and abroad.

Production Process

Certifications

Frequently Asked Questions

Q1: Are you a trading company or a manufacturer?

A: We are a factory. We specialize in micro DC motors and DC gear motors with over 14 years of experience.

Q2: What is the payment term for new customers?

A: We can arrange online trade assurance orders for new clients, supporting Master Card, Visa, PayPal, T/T, and more.

Q3: Can you customize the motor if I cannot find a suitable model on your website?

A: Yes, we can fully customize motor specifications, sizes, and gearboxes based on our customers' specific requirements.

Q4: Do you hold proper quality certifications for the motors?

A: Yes, our products conform to CE, FCC, ISO, and other relevant standard requirements. We can also apply for additional specific certifications if required.

Q5: How is your quality control structured?

A: We place professional inspection staff on every production line. Once complete, finished motors are comprehensively tested using equipment such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers.

Q6: What is the typical lead time for customized motor orders?

A: The lead time depends on the customization complexity and order volume. Typically, custom samples take 1-2 weeks, while mass production orders are completed within 3-4 weeks.
