SRC-280 12v Dc Electric Motor Bicycle SRC-280A Micro Dc Motor Shunli Motor Strong or Normal One for Option Permanent Magnet 42g

SRC-280 12v DC Electric Motor Bicycle

Promotion

Product Description

PMDC MOTOR Technical Data
PMDC MOTOR Model		Rated Voltage (V)		No-Load		Rated				Stall
PMDC MOTOR Model		Operating Range	Nominal	Speed (RPM)	Current (mA)	Speed (RPM)	Current (mA)	Torque (mN.m / gf.cm)	Power (W)	Current (mA)	Torque (mN.m / gf.cm)
FK-280SA	4525	1.0~2.0	1.2VDC	8670	730	6560	2240	1.74 / 17.7	1.3	8430	9.61 / 98
FK-280SA	16245	6.0~12.0	12VDC	7300	60	6027	290	3.4 / 34.6	2.15	1350	19.5 / 198

Detailed model specifications and parameters are listed in the table above.

Application

Certifications

Why Choose Us

1. Factory Strength

We are a factory specializing in motor manufacturing for more than 14 years. A professional R&D team, mature management, and experienced engineering and sales teams ensure a high-quality purchasing experience.

2. Quality Control

To guarantee quality, every step from incoming materials to final shipment is carefully inspected. Quality is the core foundation of our development.

3. Professional Service

High Credibility

Established reputation with highly verified standards of reliability.

On-Time Delivery

100% on-time delivery rate ensures your products arrive exactly when expected.

Fast Prototyping

Standard samples produced within 2 weeks. Customized samples produced within 3 weeks.

Quick Response

Dedicated support channel ensuring your inquiries are replied to within 2 hours.

Recommend Products

FAQ

1 Are you a trading company or a manufacturer?

We are a factory. We specialize in micro DC motors and DC gear motors for more than 14 years.

2 What is the payment term for a new customer?

Orders can be drawn up online for our new customers to pay with MasterCard, Visa, etc. Customers can also pay with PayPal or TT.

3 If I can't find a suitable motor on your list, can you customize the motor for me?

Yes, we can customize a suitable motor according to our customer's specific technical requirements.

4 Do you have certificates for the motors?

Yes, we have CE, FCC, ISO, etc. If you have other specific certificate requirements, we can apply for them on your behalf.

5 How is your quality control managed?

We have professional testing staff inspecting every stage of the production line. Once the motor assembly is completed, we run tests on specialized testing equipment, including Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise Testers.

6 What is the operational voltage range of the FK-280SA motor?

The operational voltage range varies depending on the specific model type: the 4525 model operates within 1.0~2.0V DC (1.2VDC Nominal), while the 16245 model operates within 6.0~12.0V DC (12VDC Nominal).
