Strata Motor
Strata Motor
| Ratio | 241k |
| Max. Rated Torque | 1.5~2.0 Kgf.cm |
| Max. Gear Breaked Torque | 4~5 Kgf.cm |
| Gearbox Efficiency | 45%~60% |
| Model | Ratio | Voltage (V) | No-Load | Rated | Stall | ||||
|---|---|---|---|---|---|---|---|---|---|
| Speed (RPM) | Current (mA) | Speed (RPM) | Current (mA) | Torque (Kgf.cm) | Current (mA) | Torque (Kgf.cm) | |||
| GM2215FMN20-241K | 1:241 | 4.5 VDC | 43 | ≤ 50 | 34 | ≤ 120 | 25/250 | ≤ 350 | 0.15/1.5 |
| 58 | ≤ 65 | 50 | ≤ 130 | 28/280 | ≤ 680 | 0.18/1.8 | |||
| 68 | 75 | 56 | ≤ 140 | 30/300 | ≤ 750 | 0.2/2.0 | |||
| Motor Model | Voltage | No-Load Speed | No-Load Current | Rated Speed | Rated Current | Stall Torque |
|---|---|---|---|---|---|---|
| SL-N20-04510500 | 4.5VDC | 10500 RPM | ≤ 30 mA | 8250 RPM | ≤ 80 mA | 1.05 gf.cm |
| SL-N20-04514000 | 4.5VDC | 14000 RPM | ≤ 40 mA | 12000 RPM | ≤ 130 mA | 1.5 gf.cm |
| SL-N20-04516500 | 4.5VDC | 16500 RPM | ≤ 50 mA | 13500 RPM | ≤ 160 mA | 1.8 gf.cm |
We are a factory specializing in producing motors for more than 14 years. Our professional R&D team and mature management ensure a superior shopping and product experience.
To guarantee quality, every step from raw material reception to final shipment is carefully checked. Quality is the foundation of our development.
