Strata Motor
Strata Motor
Product Details
BLDC MOTOR Terminations
| PIN NO. | PIN Arrangement |
|---|---|
| 1 | VCC |
| 2 | FG |
| 3 | CW/CCW |
| 4 | GND |
| 5 | PWM |
1. Professional Manufacturing
We are a factory specializing in producing motors for more than 14 years. Our professional R&D team and mature management ensure a pleasant experience for all customers.
2. Stringent Quality Control
To ensure high quality, every step from material reception to shipment is carefully checked. Quality is the foundation of our development.
We are a trusted seller with high credibility in the motor industry.
100% on-time delivery rate to ensure your products arrive timely.
Standard samples produced within 2 weeks; customized samples within 3 weeks.
Timely response: all messages will be replied to within 2 hours.
A: We are a factory. We have specialized in micro DC motors and DC gear motors for more than 14 years.
A: We support various payment methods including Online Assurance Orders (MasterCard, Visa), PayPal, and TT.
A: Yes, we can customize motors according to our customers' specific technical requirements.
A: Yes, we have CE, FCC, ISO, and other certifications. We can apply for additional certificates if required.
A: We have professional staff on every production line. We use advanced equipment like Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, and Noise Testers to ensure complete quality.
A: Standard samples are typically ready within 2 weeks, while customized solutions take approximately 3 weeks.
