Strata Motor
Strata Motor
Product Details
Gearbox Technical Data
| Ratio | 41K / 82K / 95K / 190K / 219K / 438K / 504K / 1007K |
| Max. Rated Torque | 300~800 gf.cm |
| Max. Gear Breaked Torque | 1000~3000 gf.cm |
| Gearbox Efficiency | 12%~35% |
Gearmotor Technical Data
| Model | Ratio | Voltage (V) | No-Load | Rated | Stall | ||||
|---|---|---|---|---|---|---|---|---|---|
| Speed(RPM) | Current(mA) | Speed(RPM) | Current(mA) | Torque(gf.cm) | Current(mA) | Torque(gf.cm) | |||
| GM1220EMN20-95K | 1 : 95 | 4.5 VDC | 145 | ≤ 70 | 122 | ≤ 200 | 80 | ≤ 700 | 750 |
| GM1220EMN30-1007K | 1 : 1007 | 12 VDC | 25 | ≤ 90 | 22 | ≤ 230 | 1200 | ≤ 400 | 4200 |
PMDC MOTOR Technical Data
| Model | Length (mm) | Voltage (V) | No-Load Speed | No-Load Current | Rated Torque (gf.cm) | Stall Torque (gf.cm) |
|---|---|---|---|---|---|---|
| SL-N20 | 15 | 4.5 VDC | 14000 | ≤ 40 | 2.5 | 15 |
| SL-N30 | 20 | 12 VDC | 25400 | ≤ 50 | 5 | 42 |
As a high-tech enterprise integrating research, development, production, and sales, we specialize in various kinds of micro DC motors, geared motors, planetary geared motors, shade pole geared motors, and special gearbox motors.
Our products are widely used in automobiles, communications equipment, smart homes, medical equipment, intelligent security, household appliances, and other high-end transmission structures. With a commitment to quality, our products are exported to more than 50 countries and regions worldwide.
