Strata Motor
Strata Motor
Our motors are engineered for longevity, high efficiency, and exceptional stability. The integrated drive system ensures accurate data capture for advanced project requirements.
| Model | Voltage | No-load | Load | Stall | ||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Working (V) | Rated (V) | Speed (rpm) | Current (A) | Speed (rpm) | Current (A) | Torque | Output (W) | Stall Torque | Current (A) | |||
| Range | V | rpm | A | rpm | A | N.m | Kg.m | W | N.m | Kg.m | A | |
| SGP01S-A130-14150-120 | 3-12.0V | 4.5 | 100 | 0.2 | 87 | 0.5 | 0.066 | 0.675 | 0.4 | 0.265 | 2.7 | 1.25 |
| SGP01S-A130-18100-220 | 3-12.0V | 3.0 | 50 | 0.2 | 40 | 0.3 | 0.120 | 1.233 | 0.6 | 0.393 | 4.003 | 2.15 |
We operate three specialized factories with over 14 years of expertise in motor production. Our professional R&D teams and experienced engineers ensure a superior product experience.
Quality is the foundation of our development. Every step, from raw material reception to final shipment, is carefully checked to maintain the highest standards.
Trusted global supplier with a proven track record.
Ensuring your products arrive according to schedule.
Standard samples in 2 weeks; customized in 3 weeks.
All inquiries are addressed within 2 hours.
A: We are a dedicated factory specializing in micro DC motors and gear motors with over 14 years of industry experience.
A: Yes, we provide full customization services to modify technical parameters and dimensions according to your specific requirements.
A: Our products are certified with CE, FCC, ISO, and other relevant standards. We can also apply for specific certificates upon request.
A: We employ professional staff at every production stage and use advanced testing equipment, including Hardness Testers, 2.5D Image Testers, and Salt Spray Chambers.
A: Standard samples are usually produced within 2 weeks, while customized samples typically take approximately 3 weeks.
A: We support various secure payment options including online assurance orders (Visa/MasterCard), PayPal, and TT transfers.
